Ibanez JS2470-CS Joe Satriani: Technical Review

The Ibanez JS2470-CS is a Joe Satriani signature guitar with a familiar ST-style outline and a feature set built around two distinct pickup functions. Its bridge position uses a DiMarzio Satchur8 humbucker, while the neck position holds a Sustainiac Driver. The listed controls include separate push/pull functions for high-pass operation and Sustainiac control, plus dedicated three-way switches. That combination makes the switching layout one of the central points to examine when assessing this instrument on paper.

The specifications list a price of 2,869, availability from October 2026, and Japanese manufacture. The guitar comes with a case, but not a separate bag. No customer reviews are available, so this assessment is based solely on the supplied construction and hardware details. Those details establish what the model includes, but they do not confirm how it feels in use, how well it is set up from the factory, or how it performs in a particular playing situation.

Body, Neck, and Fingerboard

The body is alder, with no separate top listed. Its Cherry Sunburst finish is high gloss, and the hardware is chrome. The neck is a three-piece, bolt-on construction made from maple and bubinga. Ibanez specifies a JS neck profile, measuring 20 mm thick at the first fret and 22 mm at the twelfth. Those measurements give a more useful description of the neck's dimensions than the profile label alone, although they cannot fully convey its feel in the hand.

The rosewood fingerboard carries 24 medium frets and abalone dot inlays. Luminlay side position markers are also specified. The fingerboard radius is 250 mm, or 9.843 inches, and the nut width is 42.8 mm, or 1.685 inches. Together with the 648 mm, or 25.5-inch, scale length, these measurements describe a full-scale neck with a relatively broad playing surface compared with the nut measurement. The available information does not specify fret material or fret treatment.

Pickups and Controls

At the bridge, the DiMarzio Satchur8 is a humbucker. At the neck, the Sustainiac Driver serves a different role, providing the guitar's Sustainiac system. A three-way Sustainiac mode switch is listed, along with a separate three-way pickup switch. The volume control has a push/pull high-pass function, and the tone control has a push/pull function for Sustainiac. This control scheme gives the player several ways to configure the electronics, though the supplied specifications do not explain the exact switching combinations or operating instructions.

The pairing of one conventional bridge humbucker and a neck-position driver is a notable departure from a standard two-pickup layout. Buyers should make sure they understand the Sustainiac system and its controls before choosing the guitar, particularly if they expect a conventional neck pickup. The product information identifies the components and control functions, but does not provide output measurements, wiring diagrams, or detailed tonal descriptions.

Tremolo and Hardware

The JS2470-CS uses an Edge tremolo and a locking nut. These are the specified components associated with its tremolo and tuning setup. Gotoh machine heads are fitted, and the strings are listed as.009 to.042 gauge. The specifications do not state whether the tremolo includes additional accessories, nor do they describe its adjustment range or setup procedure. A buyer considering alternate string gauges should account for the work that may be required to balance and set up a tremolo system.

The finish, chrome hardware, and included case complete the listed package. The model is identified as made in Japan, and its item number is 652368. It is supplied as one piece. These details are useful for confirming the exact version and what is included, particularly when comparing listings that may use similar model names.

Who Should Consider It?

The specification sheet points toward players seeking a Joe Satriani signature instrument with a 24-fret rosewood fingerboard, an Edge tremolo, and Sustainiac functionality. Its controls and pickup arrangement warrant more attention than a basic two-pickup guitar, so prospective buyers should review the switching layout and confirm that the Sustainiac system suits their needs. The full-scale length, locking nut, and stated.009 to.042 strings provide further reference points when assessing fit with an existing setup.

There is not enough evidence here to make claims about comfort, tuning stability in practice, finish quality, or sound. Those questions require direct inspection or reliable hands-on reporting. Based on the supplied specifications, the JS2470-CS is a clearly equipped Japanese-made signature model with a focused combination of tremolo hardware and Sustainiac electronics. Its value depends on whether those specific features justify the listed price of 2,869 for the intended player.
