Evh 5150 DX Baked Maple Black
The EVH 5150 DX pairs two Wolfgang humbuckers with a Floyd Rose 1000 tremolo and D-Tuna. Its performance-focused hardware and roasted maple construction are compelling, though a case is not included.
★★★★★ 4.5/5 · 2 buyer reviews · 6 min read · updated 2026-10-07 · Tested by Cal Whitaker
Evh 5150 DX Baked Maple Black: Technical Review
The Evh 5150 DX Baked Maple Black is a six-string electric guitar specified with a basswood body, a roasted maple neck and fingerboard, two direct-mount EVH Wolfgang humbuckers, and a Floyd Rose locking tremolo. Its listed price is 1044, with no currency specified in the supplied product data. The model has been available since March 2026 and is identified by item number 636052.
This review is based solely on the supplied specifications. No customer reviews are available, so there is no basis here for claims about players' experiences, build consistency, sound quality, or long-term reliability. The details below describe the guitar's stated construction and hardware, along with the practical implications those specifications support.
Body and neck construction
The body material is listed as both linden and basswood in the source specifications. Those names refer to the same wood category, so the guitar can be described as having a basswood body. No separate top is specified. The finish is black, and the hardware is chrome. The data does not provide a body thickness, weight, or finish type, so those details cannot be assessed.
The neck is bolt-on and made from quarter-sawn roasted maple. Its fingerboard is also roasted maple, with black dot inlays. The neck profile is described as an EVH Modified "C" back shape. The supplied details do not give a neck thickness measurement or a breakdown of the profile at specific fret positions, which limits comparisons with other necks.
The compound fingerboard radius runs from 12 inches to 16 inches, or 304.8 to 406.4 mm. The listed specification describes a flatter radius toward the upper end of that range. The guitar has 22 jumbo frets, a 42.86 mm nut width, and a 648 mm scale length, equivalent to 25.5 inches. These measurements give a useful outline of the playing surface, but they do not establish fret height, fret material, or setup condition.
Pickups and controls
The pickup configuration is HH, with two direct-mount EVH Wolfgang humbuckers. Direct mounting identifies how the pickups are attached, but the supplied information does not include pickup output, magnet type, coil wiring options, or individual pickup specifications. No detailed tonal claims can be made from the pickup names alone.
Controls consist of one volume control with a treble-bleed circuit and one tone control. A three-way switch selects between pickup positions, and a separate kill switch is listed. The treble-bleed circuit is part of the volume control specification; its exact component values are not provided. The data also does not describe the kill switch's physical position or operation beyond identifying its presence.
Bridge, tuning hardware, and strings
The guitar has a top-mounted, EVH-branded Floyd Rose 1000 locking tremolo, paired with a Floyd Rose R3 locking nut. An EVH D-Tuna is also included in the listed bridge hardware. Together, these specifications identify a locking tremolo setup with a matching locking nut. The source does not state whether the bridge is recessed, describe its setup range, or provide details about adjustment tools.
EVH-branded Gotoh machine heads are specified, along with chrome hardware throughout. The listed strings are EVH nickel-plated steel in a.009 to.042 gauge set. String gauge is useful for understanding the supplied setup, though it does not confirm whether the instrument is shipped with a particular tuning or whether the setup suits every player's preferences.
What the specifications establish
The stated feature set is specific: a basswood body, roasted maple neck and fingerboard, 22 jumbo frets, a compound-radius board, two Wolfgang humbuckers, and locking Floyd Rose hardware. These details may help shoppers compare the model with other guitars in a similar category. They do not, by themselves, confirm the instrument's weight, acoustic resonance, pickup response, factory setup, or consistency from one unit to another.
No gig bag or case is included according to the supplied listing. Buyers should account for that when considering the total cost of ownership, especially if they need to transport or store the guitar in a fitted case. The sale unit is one piece. No additional accessories are identified.
Verdict
The Evh 5150 DX Baked Maple Black is defined by its roasted maple neck and fingerboard, dual Wolfgang humbuckers, and locking tremolo system with an R3 nut and D-Tuna. Its dimensions and controls are clearly listed, making the specification sheet useful for an initial comparison. However, there are no customer reviews or hands-on test results in the available information. Potential buyers should treat this as a feature-based assessment, then verify the instrument's setup, weight, and feel with a retailer before purchase where possible.
Shipping and duties
The retailer ships from its warehouse in Germany. Prices are shown in US dollars and do not include import duties. Orders under roughly $800 usually clear US customs without duty; above that, a duty of a few percent may be collected on delivery. 30-day money-back and a 3-year warranty apply.
Scores by area
Where it shines, where it stumbles
What convinced me
- Two direct-mounted EVH Wolfgang humbuckers and a treble-bleed volume circuit offer a focused, adjustable pickup setup.
- The Floyd Rose 1000 locking tremolo includes an EVH D-Tuna for changing the low string between standard and dropped tuning.
- A quartersawn roasted maple neck, compound-radius fingerboard, and 22 jumbo frets provide a performance-oriented specification.
What bugged me
- No gig bag or case is included.
- The locking tremolo and locking nut may require more involved string changes and tuning adjustments than a fixed bridge.
Is it the right one for you?
Good pick if
A good fit for players seeking a locking tremolo, quick dropped-tuning changes, and a two-humbucker layout. Also suited to guitarists who prefer a roasted maple neck and compound-radius fingerboard.Look elsewhere if
Not ideal for buyers who want a case included or prefer a low-maintenance fixed bridge. Players who do not need a locking tremolo may find its setup less convenient than simpler alternatives.Suggested level: Intermediate
Specifications
- Color
- Black
- Body
- Linden
- Top
- None
- Neck
- Roasted Maple
- Fretboard
- Roasted Maple
- Frets
- 22
- Scale
- 648 mm
- Pickups
- HH
- Tremolo
- Floyd Rose
- Incl. bag
- No
- Including case
- No
Up close
Watch and listen
Before you decide
Questions players ask
Does the guitar include a case or gig bag?
No. The product specifications state that neither a case nor a bag is included.
What pickups does the EVH 5150 DX have?
It has two direct-mounted EVH Wolfgang humbuckers, controlled by one volume knob with a treble-bleed circuit, one tone knob, and a three-way switch.
What does the D-Tuna do?
The EVH D-Tuna is fitted to the Floyd Rose 1000 locking tremolo and allows a quick change of the low string between standard tuning and dropped tuning.
What are the neck and fingerboard specifications?
The bolt-on neck and fingerboard are roasted maple. The neck has an EVH Modified C profile, a compound radius from 12 to 16 inches, and 22 jumbo frets.
Is this guitar a good choice for a first electric guitar?
It could suit a motivated beginner, but the locking tremolo and locking nut can be more demanding to adjust than a simpler fixed bridge. It is most directly suited to players who specifically want this tremolo setup.
The last word from the bench
The EVH 5150 DX is specified for players who want a locking tremolo, an onboard D-Tuna, and a straightforward two-humbucker layout. Its compound-radius roasted maple fingerboard and jumbo frets are geared toward fast, expressive playing. The listed hardware is extensive, but the lack of an included bag or case adds a likely extra purchase. With no customer reviews available, its real-world performance cannot be assessed from buyer feedback.
