ESP M7B HT RASPBERRY GH EMG

Overview and Construction

The ESP M7B HT RASPBERRY GH EMG targets players who insist on no-compromise build quality, modern playability and powerful electronics in a 7-string configuration. Available since September 2025 and made in the USA, this model is firmly positioned as a high-level professional instrument. With a price point of $5599 and a distinctive raspberry matte finish over a figured maple top, it is a bold statement in both looks and performance-ready specifications.

Body and Neck Materials

The foundation of the guitar is a mahogany body, chosen for its balanced resonance and sustain. The top features figured maple, lending visual depth and adding brightness to the tonal spectrum. The bolt-on neck is crafted from maple, giving additional attack and clarity, while the fingerboard is made from rosewood, chosen for both its smooth playability and traditional tonal warmth. Together, these materials combine to offer a balanced sound foundation, suitable for extended-range guitars.

• Body: Mahogany
• Top: Figured maple
• Neck: Maple, bolt-on construction
• Fingerboard: Rosewood, 305 mm (12-inch) radius

Neck Profile, Frets, and Playability

ESP has applied an extra thin "U" profile for the neck, which is designed to maximize speed and comfort during technical playing. The scale length measures 686 mm (27 inches), defining the M7B as a baritone-range 7-string. This extra scale length ensures optimal string tension for lower tunings and sharper note definition across all strings. The 48 mm (1.89 inch) wide bone nut creates needed string spacing for chordal and solo approaches common in progressive and modern metal styles.

The rosewood fingerboard houses 24 super jumbo frets, giving access to a full two-octave range on each string and making high-register bends more accessible. With a 305 mm (12-inch) radius, the fingerboard strikes a balance between chord comfort and straightforward solo runs.

• Scale length: 686 mm (27 inches, baritone)
• Frets: 24, super jumbo size
• Neck profile: Extra thin "U"
• Nut: Bone, 48 mm (1.89 inch) width

Pickups and Electronics

The electronics suite features two active humbuckers from EMG: the 81-7XH in the bridge and the 85-7XH in the middle position. This combination targets maximum output, definition and noise-free operation, with a tonal palette suited to modern aggressive styles. These pickups are recognized for high signal clarity, tight low frequencies, and searing leads. A traditional 3-way toggle switch, volume and tone controls provide familiar wiring and straightforward tone shaping on stage or in the studio.

• Bridge position: EMG 81-7XH humbucker
• Middle position: EMG 85-7XH humbucker
• Controls: Volume, tone, 3-way toggle switch

Hardware and Setup

No tremolo system is present; instead, the ESP M7B HT is equipped with a Hipshot fixed bridge, chosen for its tuning stability and precise intonation. Machine heads come from Gotoh, employing a locking configuration for quick and secure string changes. The instrument includes gold hardware throughout, visually tying together the raspberry finish with a touch of luxury. D'Addario NYXL strings in.009 to.054 gauge come factory-installed, an appropriate pairing for clarity and flexibility across the extended range.

As expected at this price point, the ESP M7B HT ships in a hard case and includes a Dunlop Straplok system for added instrument security on stage. A gig bag is not included in the package.

• Bridge: Hipshot fixed
• Machine heads: Gotoh, locking
• Strings: D'Addario NYXL,.009,.054
• Hardware: Gold
• Accessories: Hard case, Dunlop Straplok system included

Design and Aesthetics

This guitar finds its identity not just in its upscale components but also in its visual presentation. The raspberry matte color combined with the figured maple top sets this model apart on any stage. Attention to detail continues with gold hardware, which complements the distinctive finish without being ostentatious.

Conclusion

ESP delivers a no-compromise, US-built 7-string that brings together a professional-scale design, premium woods, rugged hardware and high-output active electronics. The combine of a baritone scale, extra thin neck profile and EMG pickups ensures technical players and modern metal musicians will find the ESP M7B HT RASPBERRY GH EMG ready for demanding environments. The specification list reflects careful component choices and a clear focus on both durability and playability. For those in search of reliability, technical accuracy and modern aesthetics, the investment matches the promise of a stage-worthy professional instrument.
